Automatic Chemiluminescence Analyzer
Boundless Vision, Mastering Time
Utilizes acridine ester direct chemiluminescence technology based on magnetic microparticles
Precision manufacturing and a robust traceability system
ensure accurate and reliable test results
600 T/H High-Speed Analysis
9 min Quick Result
meeting emergency TAT requirements
Seamless Reagent Loading
Auto Maintenance, Hassle-Free
Flexible system configuration to optimize laboratory space
High-efficiency processing ensures timely delivery of test results
Optimized magnetic separation and dispensing system for enhanced precision and stability
Real-time self-diagnosis and proactive error warnings ensure uninterrupted operation
Dual-backup substrate and wash solutions enable 6-hour unattended operation
Solid-liquid separation post-reaction with direct liquid waste discharge enhances biosafety
Maximum throughput of 600 tests per hour
Fastest first test result in 9 minutes
Compact footprint of 1.1㎡
Space efficiency of 545 tests per hour per square meter
Core sample processing functions achieved in just 0.35㎡
Sample decapping and visual recognition without a dedicated processing system
Serum quality detection+helical decapping+sample buffering
-
Preloaded reagents for seamless workflow
-
Continuous reagent replacement
-
Uninterrupted reaction cup loading
-
Multi-screen operation
Real-time instrument status monitoring
Clear reagent consumption tracking
Intuitive Setup, Effortless Operation
Comprehensive and practical functional applications
ully automated, random-access analyzer
Acridine ester chemiluminescence technology
600 T/H
≤ 9min
Track-based sample loading
Up to 50 samples simultaneously, expandable for continuous loading
Supports auto-retest and priority emergency sample testing
5μL~150μL
≤ 0.1ppm
Liquid level detection, clog detection, volume tracking, collision protection
Serum, plasma, whole blood, urine, cerebrospinal fluid, and other bodily fluids
20μL~ 100μL
2℃ ~ 8℃
Real-time online mixing
Auto-loading, continuous supply
Compatible with common immunoassay modes
Non-contact mixing technology
Quadruple magnetic separation technology
Windows 10+ compatible
User-defined scheduling
10℃~30℃
30%~70%
64kPa~106kPa
220V~, 50Hz, 2000VA
Approx. 454kg per unit
1156 × 969 × 1305 mm (L × W × H)
Standard direct drainage, optional waste container
Around 20-25 L/H per module（Continuous working）
< 63 dB
